Installation PA Mixer AMPLIFIERS
AC & 24V DC Operation
|
Power Output |
415W Max., 325W RMS at 10% THD, 300W RMS at 5% THD, 275W RMS at 2% THD |
|
Output Regulation |
≤ 2 dB, no load to full load at 1kHz |
|
Input Channels |
3 × Mic 0.65mV/4.7kΩ, 2 × Mic 1.0mV/2kΩ, 1 × Line 1V/50kΩ, 2 × Aux 100mV/470kΩ, 1 × Aux 250mV/470kΩ, 1 × Telephone 150mV/10kΩ |
|
Frequency Response |
50-15,000Hz ±3dB |
|
Signal to Noise Ratio |
60dB |
|
Tone Controls |
Bass: ±10dB at 100Hz, Treble: ±10dB at 10kHz |
|
Outputs |
Preamp 200mV/600Ω, Line 1V/1kΩ, Monitor 5V/8Ω |
|
Speaker Outputs |
4Ω, 8Ω, 70V & 100V |
|
Zone Selection |
5 + All Zone |
|
Power Supply |
AC: 220-240V 50/60Hz DC: 24V (2×12V Car Battery) |
|
Power Consumption |
AC: 600VA DC: 7A |
|
Dimensions |
W482 × H133 × D390 mm |
|
Weight |
19.8kg |
